Feature
Low Insertion loss,Low return loss
High Channel Separation
High Stability and Reliability
No Plastic Optical Path
Parameter | Symbo l | Unit | Min | Typ | Max | Test Condition | |
Pass Channel Wavelength Range | λ | nm | 1539 | 1550 | 1565 | - | |
Reflect Channnel Wavelength |
λ |
nm | 1260 | 1310 | 1360 | ||
1480 | 1490 | 1500 | |||||
Responsivity | R | A/W | 0.85 | Vr=5V, λ1550nm | |||
Isolation | Pass Channel |
Iso |
dB | 35 | λ=1310nm, λ=1490nm | ||
Reflect Channel | 20 | Λ=1550nm | |||||
Polarization dependent loss | Pass Channnel |
PDL |
dB | 0.05 | |||
Reflect Channel | 0.05 | ||||||
Directivity | D | dB | 50 | ||||
Return Loss | RL | dB | -45 | ||||
Insert Loss | Pass Channnel |
IL | dB | 0.8 | |||
Reflect Channel | dB | 0.6 | |||||
