Feature
High responsivity, low return loss
Low dark current, low capacitance
Planar incident structure
High reliability and long operation life
Parameter | Symbol | Unit | Min | Typ | Max | Test Condition |
Operating Wavelength | λ | nm | 1100 | 1650 | - | |
Dark Current | Id | nA | 1 | Vr=-5V 25℃ | ||
Responsivity |
R | A/W | 0.87 | Vr=-5V λ=1310nm | ||
0.95 | Vr=-5V λ=1550nm | |||||
Active Diameter | Φ | μm | 55 | - | ||
Rise time/Fall time | tr/tf | ns | 0.1 | RL=50Ω | ||
Capacitance | C | pF | 0.46 | 0.65 | Vr=-5V | |
Composite Second Order Beat |
IMD2 | dBc |
-75 | |||
Composite Third Order Beat |
IMD3 | dBc |
-85 | |||
Optical Return Loss | dBm | -40 |
