WSZ1 Series ONU

Optical Network Unit (ONU) is a user-side device in PON network, which provides users with access services for data and other services.The main function of the ONU device is to receive optical signals in the downstream direction and convert them into Ethernet messages to be transmitted to the users, and to convert Ethernet messages received from the user's equipment or network into optical signals in the upstream direction and transmit them to the upper-layer network through the PON network. PON network to the upper layer network.

WSZ1 series is the optical network unit (ONU) product in GPON and EPON series products developed by our company. The product uses passive optical network (PON) technology, which is superior to traditional access products in terms of cost-effectiveness, maintainability, expandability and many other aspects.


  • Feature
  • Parameter
  • Diagram

Supports GPON or EPON mode

Support SFU function

Supports PPPoe/DHCP/static IP routing mode

Support IPV4

Supports LAN IP and DHCP Server configuration

Supports port mapping and loop detection

Support Firewall function and ACL access & control list function

Supports IGMP Snooping multicast features


sports event

typology

Technical Parameters

PON

Interface Type

SC/UPC

receiver sensitivity

≤-27dBm

luminous power

+1~+4dBm

transmission distance

20Km

operating wavelength

TX:1310nm  RX:1490nm

LAN

Interface Type

1 Gigabit RJ45 port

transfer mode

10/100/1000Mbps Adaptive

Power supply related

connector

DC005 φ2.1mm

input voltage

9-12V

power wastage

≤4W

Environment-related

operating temperature

0~+50℃

Operating humidity

10~85%(non-condensing)

Storage temperature

-30~+60℃

Size Weight

Product Size

90*21*16mm(not include line)

Package Size

325*160*125mm(50pcs/box)

Net Weight

0.04kg

Total weight

2.5Kg
