Performance Characteristics
Using an erbium co-doped double-coated optical fiber technology and a low-noise pump laser.
With the display screen backlight control function, the user can adjust the backlight time as needed
It has alarm function, and support buzzer alarm.
The whole machine adopts modular design, easy maintenance and management.
Support the output power adjustable function, adjustable range + 0.5~ -4 dBm.
WDM is optional to realize the three-network fusion function.
One-button pull-out power supply design.
Item | Unit | Specification | Note | |
CATV wavelength | nm | 1545~1560 | Central wavelength 1550nm | |
PON OLT wavelength | nm | 1310/1490 | Customized 1270/1577 | |
CATV Input Power Range | dBm | -10dBm~+10dBm | ||
Output Power Stability | dB | ±0.1 | ||
Noise | dB | ≤6 | ||
Return Loss | Input | dB | ≥45 | |
Output | dB | ≥45 | ||
OSW | Input port | 2 | Optional | |
Insertion loss | dB | ＜1.3 | ||
Switching time | s | ＜0.5 | ||
Rx TEST | Output level | dBuV | ≥ 56dBuV | + 2 dBm ~ -7 dBm (analog) optional function |
≥ 56dBuV | + 2 dBm ~ -10 dBm (digital) optional function | |||
Optical connector | SC/APC；SC/PC；LC/APC；LC/PC | Customized | ||
C/N | dB | ≥50 | Test conditions are performed according to GD / J115-2020. | |
C/CTB | dB | ≥65 | ||
C/CSO | dB | ≥65 | ||
Power Supply Voltage | V | AC(90V~264V) | Optional DC or UPS | |
Consumption | W | ＜75 | ||
Operating Temperature | ℃ | -5-+50 | ||
Max Operating Humidity | % | Maximum of 95% with no condensation | ||
Storage Temperature Range | ℃ | -40~+80 | ||
Max Storage Humidity | % | Maximum of 95% with no condensation | ||
Size | mm | 296(W)*225(D)*110(H) | Without the power handle, flange plate | |
Package Size(1pc) | mm | 435(W)*375(D)*180(H) | ||
Net weight | kg | 4.8 | ||
Gross weight | kg | 5.6 | ||
