Features
The highest output power can reach 18dBm
Low noise figure, adjustable output power
The operation mode is ACC/APC
Ultra-compact structure, ultra-low power consumption
High stability, high reliability
Applications
Telecom or Datacom
CATV or SDH system
Parameter | Min | Typ. | Max | Unit | ||
Operating Wavelength | 1528 | 1550.12 | 1565 | nm | ||
Input Power | -12 | -10 | +3 | dBm | ||
Output Power | 10 | - | 17 | dBm | ||
polarization dependent gain | - | - | 0.5 | dB | ||
polarization mode dispersion | - | - | 0.5 | ps | ||
Input/output optical isolation | 45 | - | - | dB | ||
Fiber type(Input/output) | 0.9mm | - | ||||
Fiber connector (Input/output) | FC/APC（customized） | |||||
Fiber length(Input/output) | 0.5米（customized） | |||||
Noise figure | < 5.5 | dB | ||||
Supply voltage | - | +3.3 | - | V | ||
Power consumption | - | - | 10 | W | ||
