n 4K VP9 Video decoder, 4K 10-bits H.265/H.264 video decoder
n 1080P other video decoders (VC-1, MPEG-1/2/4, VP6/8)
n Support conversion from BT.2020 to Rec.709/Rec.601
n Video post processor: de-interlace
n Support H.263/H.264 2160P@ 24fps
n Support VC-1 ,MPEG - 1 1080p @ 60fps
n Support MPEG- 2 2160P @ 24fps
n Support MPEG-4 1080P @ 60fps
n Support AVS 1080p @ 60fps
n Support MVC 2160P @ 24fps
n Support WMV,3GP,MKV,ASF,3G2M4V,MJPEG,RV8,RV9,RV10 1080P@60fps
n Support HEVC decoder
n Support Main/Main10 HEVC/H.265 decoder, 4K @ 60FPS
n Support 4096x2304 resolution
n Support HDMI 720P-2160P FUII 3D HD( 2160P, 3840 * 2160 ), 4K+2 K
n Support flash11.1
CPU | RK3228A, 28nm Quad core Cortex A7, High cost performance 4K OTT Box solution |
GPU | ARM Mali-400 GPU |
HDMI | Including an HDMI 2.0 for HDMI 2.0 for 4K YUV420@30Hz with HDCP 1.4/2.2 |
Support 4K 10-bit H.265/H.264/VP9 video playback and display | |
Memory | 1GB/2GB DDR3 |
Flash | 8GB/16GB Emmc (up to 32GB) |
WiFi | 802.11 a/b/g/n 2.4G/5G |
BT | BT4.0 |
USB HOST | 2*USB2.0 |
Wired network | Ethernet GMAC 10/100M Ethernet controller |
Support 10/100Mbps data transfer rate and RGMII interface | |
IR | Infra Remote control |
Power Supply | DC input 5V/2A |
